Isolated RS485 Repeater

Product Description

Introduction

The I-7510 provides 2-way optical isolation between one piece of RS-485 equipment and the rest of the system. It can also be used as a repeater to extend the transmission of an existing network. Additionally, an RS-485 system can be expanded beyond the 256 node limitation imposed by the standard. It can also be used to convert a 2-wire RS-485 signal, and vice versa.

Isolation
Intra-module Isolation	2-way 3 kV Isolated

EMS Protection
ESD (IEC 61000-4-2)	Yes

LED Indicators
Status	1 x Power and Communication

COM Ports
Ports	1 x RS-485
Baud Rate	300 115200 bps

Power
Input Range	+10 VDC +30 VDC
Consumption	2.2 W

Mechanical
Casing	Plastic
Dimensions (mm)	72 x 35 x 122 (W x L x H)
Installation	DIN-Rail Mounting

Environment
Operating Temperature	-25 +75 C
Storage Temperature	-30 +80 C
Humidity	10 90% RH, Non-condensing
